Traffic Analysis for FastEthernet0/16

System:Switch in
Maintainer:
Interface:FastEthernet0/16 (17)
IP: ()
Max Speed: 12.5 MBytes/s (ethernetCsmacd)

The statistics were last updated Wednesday, 9 March 2005 at 17:30 ,
at which time 'Switch' had been up for 21 days, 21:08:51.
`Daily' Graph (5 Minute Average)
Max In: 145.7 kB/s (1.2%) Average In: 4149.0 B/s (0.0%) Current In: 2308.0 B/s (0.0%)
Max Out: 10.4 kB/s (0.1%) Average Out: 546.0 B/s (0.0%) Current Out: 332.0 B/s (0.0%)
`Weekly' Graph (30 Minute Average)
Max In: 72.4 kB/s (0.6%) Average In: 2225.0 B/s (0.0%) Current In: 380.0 B/s (0.0%)
Max Out: 6104.0 B/s (0.0%) Average Out: 321.0 B/s (0.0%) Current Out: 124.0 B/s (0.0%)
`Monthly' Graph (2 Hour Average)
Max In: 172.3 kB/s (1.4%) Average In: 6219.0 B/s (0.0%) Current In: 1342.0 B/s (0.0%)
Max Out: 293.4 kB/s (2.3%) Average Out: 3321.0 B/s (0.0%) Current Out: 689.0 B/s (0.0%)
`Yearly' Graph (1 Day Average)
Max In: 313.4 kB/s (2.5%) Average In: 4102.0 B/s (0.0%) Current In: 3400.0 B/s (0.0%)
Max Out: 1290.7 kB/s (10.3%) Average Out: 5264.0 B/s (0.0%) Current Out: 415.0 B/s (0.0%)

GREEN ### Incoming Traffic in Bytes per Second
BLUE ### Outgoing Traffic in Bytes per Second
